| Parameters |
Normal Mode |
UPS Mode |
| Mains AC Lower Voltage Limit |
100 ± 5VAC |
180 ± 5VAC |
| Mains AC Lower Recovery Volt. |
110 ± 5 VAC |
190 ± 5 VAC |
| Mains AC Higher Voltage Limit |
280 ± 5 VAC |
260 ± 5 VAC |
| Mains AC Higher Recovery Volt. |
270 ± 5 VAC |
250 ± 5 VAC |
| Output Voltage with full load in Normal Mode |
220 ± 10 V |
- |
| Battery Low Cut-Off Voltage |
10.4 ± 0.2 V (per Battery) Default |
| Mains O/P Frequency |
Same as Input |
| INV. O/P Frequency |
50 ± 1.0 Hz |
| Battery Charging |
| Battery Charging Volt. Range |
100 to 280 V |
180 to 260 V |
| Trickle Charging Current Limit |
0.5 ± 0.3A |
0.5 ± 0.3A |
| Boost Voltage |
14.4 ± 0.1 V (per Battery) |
| Float Voltage |
13.7 ± 0.2 V (per Battery) |
| Overload |
100 + 3% (with Auto reset function) |
| Short Circuit Protection |
> 300% Load (with manual reset function) |
| Change Over Time |
< 60m Sec |
< 10m Sec |
| Max. Charging Current (when battery is fully discharged) |
| 3.8 KVA |
20 ± 1 A |
| 5.5 KVA (48V) |
24 ± 1 A |
| 5.5 KVA (96V) |
16 ± 1 A |
| 20 KVA (360V) |
16 ± 1 A |
